Small stage lighting plot
A small-stage lighting plot for planning washes, backlight, DMX addresses, stands, cables, power, haze, transport, and safety checks.
As an Amazon Associate, Beamline Stage earns from qualifying purchases. Product links may be affiliate links.
A lighting rig feels professional when the audience can see the performers, the looks change intentionally, and nobody trips over the setup.
Use this plot to plan a compact lighting rig before rehearsal, load-in, or a first paid gig.
01
Fixture roles
- Assign each light a role: front wash, side wash, backlight, accent, movement, or atmosphere.
- Keep at least one readable performance look that does not rely on strobes or movement.
- Use color to support the set instead of changing constantly because the fixture can.
02
DMX and control
- Write down fixture addresses, channel modes, and scene names before the show.
- Test controller changes at rehearsal volume and room brightness.
- Carry a spare DMX cable and know how the rig behaves if one fixture is removed.
03
Safety and transport
- Place stands outside traffic paths and secure knobs before doors open.
- Tape cable crossings with real gaffer tape and route power thoughtfully.
- Pack lights, controllers, clamps, tape, and cables in dedicated bags or cases.
Mistakes this checklist prevents
- Buying moving lights before the stage has a good basic wash.
- Programming every fixture in sound-active mode and calling it a show.
- Forgetting bags, tape, spare DMX cable, and power planning until load-in.
